FIRE RESISTANCE DOORS & PARTITIONS
Howard Yarnold is able to provide Secur II, a fire resistant and thermally insulated aluminium system with a frame depth of 75mm, offering 30 minutes fire resistance for applications of fixed glazing and doors.
Our Products
Fire Resistant Doors & Barriers
Howard Yarnold is able to provide Secur II, a fire resistant and thermally insulated aluminium system with a frame depth of 75mm, offering 30 minutes fire resistance for applications of fixed glazing and doors. Inward or outward opening doors in single or double door configurations are available as well as a wide range of hardware to suit commercial, residential and industrial applications.
Designed to comply with the requirements of Secured by Design and manufactured under ISO 9001.
Colourfast GRP skin to minimise the appearance of scratches. Matching frames available to perfectly complement woodgrain doors.
Features
Secur II profiles have 5 chambers to ensure optimum stability making it possible to fabricate fire resistant doors up to 2700 mm in height, fixed screens up to 4500 mm in height and can be used for both internal and external applications.
The system can accommodate fire resistant glass or infill panels up to 32 mm in thickness
The system can accommodate fire resistant glass or infill panels up to 32 mm in thickness
The glass is centrally positioned in the profiles by means of fire resistant EPDM gaskets and retained by stainless steel security clips.
Intumescent strips fully protect the areas between the hardware groove, the glass and profiles thus avoiding the need to insert additional insulating material inside the profiles
Intumescent strips fully protect the areas between the hardware groove, the glass and profiles thus avoiding the need to insert additional insulating material inside the profiles
The same profile can be utilized as an outer frame and vent keeping sight lines to a minimum also reducing stock levels and improving material optimization.
The flush finish to both inner and outer faces gives the system a neat and aesthetic appearance.
The flush finish to both inner and outer faces gives the system a neat and aesthetic appearance.
A wide range of hardware (locks, hinges, automatic door closers) are available to meet specific egress requirements.
Secur II when manufactured, installed and glazed strictly in accordance with our recommendations can achieve 30 minutes fire resistance for both integrity and thermal insulation (subject to the correct glass specification) when tested to EN 1634-1.
Secur II when manufactured, installed and glazed strictly in accordance with our recommendations can achieve 30 minutes fire resistance for both integrity and thermal insulation (subject to the correct glass specification) when tested to EN 1634-1.
The glass is centrally positioned in the profiles by means of fire resistant EPDM gaskets and retained by stainless steel security clips.
Intumescent strips fully protect the areas between the hardware groove, the glass and profiles thus avoiding the need to insert additional insulating material inside the profiles
Intumescent strips fully protect the areas between the hardware groove, the glass and profiles thus avoiding the need to insert additional insulating material inside the profiles
Only the Best
Our Product Ranges
Howard Yarnold work with a range of leading manufacturers – offering the best fire protection products to our customers using the latest technology.
